Corner Link Conveyor PTF-460
Turn PCBs 90° to change your production line direction. Essential for L-shaped and U-shaped SMT line layouts in space-constrained factory floors.
| Model | PTF-460 |
| Turn Angle | 90° |
| Max PCB Width | 460 mm |
| Conveyor Height | 900 ± 20 mm (SMEMA) |
| Interface | SMEMA compatible |
Full Specifications
| Model | PTF-460 |
| Turn Angle | 90° |
| Max PCB Width | 460 mm |
| Conveyor Height | 900 ± 20 mm (SMEMA standard) |
| Interface | SMEMA compatible |
| Power Supply | 220V / 50Hz |
Who Should Choose the Corner Link Conveyor?
L-Shaped Line Layouts
Factories where the SMT line must turn 90° at one end — for example when the building’s footprint doesn’t allow a straight line to run the full length.
U-Shaped Line Configurations
U-shaped lines require two corner conveyors — one at each end — enabling the line to run back on itself and return the operator to the starting position.
Space-Constrained Factories
When floor space prevents a straight SMT line, corner conveyors enable the line to navigate around pillars, walls, or other equipment areas.
Direction Change vs Shuttle
Use a corner conveyor for direction changes within a single line. For transferring boards between two separate parallel lines, choose a shuttle conveyor instead.
Related Products
Single-Track Link Conveyor PTD-460
Standard straight connection between the corner and the next equipment.
View Details →
Flipper Link Conveyor PTG-460
180° board flip for double-sided SMT — pairs with corner in U-shaped lines.
View Details →
Gate Link Conveyor
Route boards to different branches — useful at corners where lines diverge.
View Details →Design Your Line Around Your Floor Space
Our engineers will plan the corner and conveyor configuration that fits your factory layout.
Request a Quote
